Project Description

SAE 100 R4 Hydraulic oil suction and delivery hose

SAE 100 R4 Hydraulic oil suction and delivery hose

Hose Type: Mandrel Built
Tube: hydraulic oil resistant special synthetic rubber
Reinforcement: High tensile synthetic textile and steel wire helix
Cover: Oil, heat, abrasion, ozone and weather resistant special synthetic rubber
Application: In oil return lines of hydraulic systems of industrial and agricultural
Temperature: -40℃ to +121℃
Cover: Wrapped Surface

SAE 100 R4 Oil Suction & Delivery Hose

SAE 100 R4 oil suction and delivery hose for use in low pressure and vacuum applications with petroleum-base hydraulic fluids within a temperature of -40ºC to +100ºC, and with water-base hydraulic fluids within the temperature ranges agreed upon by the manufacturers of both the hose and the fluid.

JYM industrial rubber hose suitable for petroleum based hydraulic oil and water-glycol based fluids, lubricating oils, air and water. A high quality oil suction hose specifically designed for hydraulic suction service.

t18

Material

Most of our rubber material imported from foreign countries( South Korea LG, Malaysia) Some bought from domestic market such as Sinopec China.

Industrial hose material

Rubber hose material

Production Process

Our Rigid Mandrel built production line can manufacture 60M length hoses.

Mandrel Built Hoes production line

Equipment

Advanced Italy VP production lines

Extruded long length hose production line

Mandrel industrial hose production line

R&D Center

Our factory has strong quality control team, we set up advanced laboratory before the mass production, we test each batch of raw material. After the production, we test each hose to guarantee a 100% qualification. Each hose tested 2 times of working pressure before packing.

Laboratory

JYM Laboratory

Warehouse

JYM Industrial hose warehouse

* For more information of JYM products, please contact us. If you would like a quotation or further information, please fill in the form below and we will reply to you within 1 working day.
